MikroTik Cloud Router Switch CRS318-16P-2S+OUT, netPower 16P, 256MB RAM, 16×G-LAN PoE-out, 2×SFP+, RouterOS L5/SwitchOS

• NetPower 16P or CRS318-16P-2S+OUT is an outdoor 16-port Gigabit PoE switch for powering IP cameras, PTP or PTMP Wireless devices with a maximum consumption of 34W/port, total PoE budget 300W, IP55 protection and wall or mast mounting. • The switch offers two voltage inputs: higher (>30V) and lower (<30V) voltage. In the case of higher voltage, the device can supply 802.3af/at standards, in the case of lower voltage it is only passive PoE.

• Connectors and Interfaces
• LAN speed:(16) 10/100/1000Mbps
• Gigabit LAN:Yes
• Optical interfaces:(2) 10Gbps
• Power
• Power type:DC connector
• PoE type:PoE-Out (only)
• PoE-Out standards:802.3af, 802.3at, Passive 54V, Passive 24V, Passive 48V
• PoE Out ports:16
• PoE budget [W]:300
• Max. power consumption [W]:16
• Power via connector/terminal:18 .. 57V DC
• Physical characteristics
• Protection class:IP55
• Design:Outdoor
• Fans:Without fan
• Chassis design:Plastic
• Operating temperature [°C]:-40 up to 70
• Width [mm]:212
• Height [mm]:303
• Depth [mm]:78
• Hardware
• CPU:98DX226S
• CPU frequency [MHz]:800
• Internal storage [MB]:16
• RAM [MB]:256
• General
• Switchning capacity [Gbps]:72
• Packet forwarding rate [Mpps]:53,6
• Software
• Web management:Yes
• Management:Web management
• Features:VLAN, QoS, DHCP snooping
• Operating system:SwOS, RouterOS - L5
• Default IP address:192.168.88.1
• Default login and password:admin / -
